THE STANDARD FOR PERFORMANCE AND DURABILITY
North Sails 3Di exemplifies outstanding value with industry leading shape holding and a longer service life compared to other sailmaking technologies. Proprietary engineering and construction methods allow 3Di sails to maintain their shape to an unprecedented level. Superyachts now use one set of 3Di sails for racing, cruising and deliveries. Volvo Ocean Race teams trust one mainsail for 35,000+ miles around the world; they formerly used two or three string laminate sails. Circumnavigators are using 3Di sails for multiple laps. Do the math, and you’ll find that 3Di sails have a lower cost of ownership than any other sails in the world.
ONLY THE ESSENTIALS
3Di sails are significantly stronger and lighter than our competitor’s laminate string sails when made of comparable materials. Filaments are the elemental form of fibers. What we think of as yarns in traditional sailcloth and string sails are in fact a twisted bundle of very small filaments, each less than the diameter of a human hair. Using filaments instead of yarns in sail constructions allows better exploitation of the fiber properties.
3Di composite construction is unique in the sailmaking industry. Like other high-performance composite structures, only fiber and adhesive are in these sails. Spread filament prepreg tapes are interleaved, in varying numbers of layers and a multiplicity of orientations, to best handle both the tension loads and the compressive forces in any given sail. The ability to precisely align fibers and vary fiber density throughout the sail membrane, optimizing the sail structure for the anticipated loads, is the essential advantage of composite construction. 3Di does not contain Mylar film, scrims, or taffetas. 3Di is not subject to the lamination problems of string sails, making 3Di sails more durable and longer lasting.
North Sails is the only sailmaker in the world to build sails on full-sized 3D molds that are inflated to each sail’s precise flying shape. Heat and vacuum pressure are then applied, consolidating the composite structure. The sail’s shape and durability are permanently locked into a rigid airfoil customized to your sailing preferences.
COMMITMENT TO QUALITY
Batten pockets, reefs, and patches are integrated into the tape structure, so finishing on a 3Di sail is minimal. Edge tapes, corner strapping and hardware are sewn by hand on the loft floor, with careful attention to detail. All North sails are manufactured in wholly-owned facilities. Our Blue Book Standards for strict construction, material and labor standards result in consistency for all of our products. 3Di quality and North’s reputation for consistency has won North Sails exclusive supplier status to the 35th America’s Cup and the Volvo Ocean Race 2017-18.
In addition to use in sails, North Thin Ply Technology has been adopted in a variety of high tech manufacturing applications. TPT flew around the world on the first non-stop solar powered aircraft and can be found in advanced golf shafts, Southern Spars masts and booms, and F1 motorcars. When using 3Di sails, you are joining an elite group who has chosen the world’s leading composite technology.
